MOSS-Image JSON Layout Tutorial: bbox, yxyx and Coordinates

Besides plain text, MOSS-Image can take a JSON layout as its prompt: one description of the whole scene, then a list of elements, each with its own bounding box. It is how you put a title, a product or a block of text exactly where you want it. OpenMOSS labels the feature experimental, but it is built into both official checkpoints, MOSS-Image-Base and MOSS-Image-SFT.

This tutorial covers the format, how the coordinates work, and how to convert boxes from a design tool.

The official exampleCopy Anchor Link

This is the example from the README, for a 1024×1024 canvas:

{
  "summary": {
    "meta": ["poster"],
    "canvas": "single",
    "caption": "A minimalist travel poster with a cream background, a blue mountain illustration, and the title EXPLORE at the top."
  },
  "items": [
    {
      "label": "text",
      "caption": "Large dark-blue uppercase title centered at the top.",
      "text": "EXPLORE",
      "bbox": [-416, -384, -288, 384]
    },
    {
      "label": "object",
      "caption": "A flat blue mountain illustration in the lower center.",
      "bbox": [-192, -288, 384, 288]
    }
  ],
  "bbox_coord_space": "abs_centralized",
  "bbox_format": "yxyx"
}

Field by fieldCopy Anchor Link

Since the docs only show meta: ["poster"] and canvas: "single", keep those values unless you have a reason to change them.

How the coordinates workCopy Anchor Link

abs_centralized means:

• Absolute pixels. Coordinates are real pixel positions on the output image, not fractions.
• The origin is the center of the canvas. On a 1024×1024 canvas, both axes run from −512 to +512.
• x grows to the right, y grows downward. So negative y is the top half of the image.

For a canvas of width W and height H, take an ordinary top-left pixel coordinate and subtract half the canvas:

x_centered = x - W / 2
y_centered = y - H / 2

And because bbox_format is "yxyx", every box is written [y_min, x_min, y_max, x_max]. Many tools use [x_min, y_min, x_max, y_max], so this is the easiest thing to get wrong.

OpenMOSS chose absolute pixels on purpose: the user guide says they believe absolute coordinates suit layout control across resolutions and aspect ratios better than relative ones. The flip side is that a layout belongs to one canvas size. Generate at the same width and height you laid it out for.

Decoding the official exampleCopy Anchor Link

Convert the two boxes back to top-left coordinates by adding 512:

• Title [-416, -384, -288, 384]: y from 96 to 224, x from 128 to 896. A band 768 pixels wide and 128 tall, centered near the top.
• Mountain [-192, -288, 384, 288]: y from 320 to 896, x from 224 to 800. A 576×576 square in the lower center.

That matches the captions: the title sits at the top, the mountain in the lower center.

Converting boxes from a design toolCopy Anchor Link

Design tools give you a box as left, top, width and height, measured from the top-left corner. This function converts one to a MOSS-Image box. It rounds outward so a box never shrinks, which matches what OpenMOSS's prompt enhancer does with fractional edges:

import math

def to_moss_bbox(left, top, box_w, box_h, canvas_w, canvas_h):
    """Top-left pixel box -> MOSS-Image [y_min, x_min, y_max, x_max] from the center."""
    cx, cy = canvas_w // 2, canvas_h // 2
    return [
        math.floor(top) - cy,
        math.floor(left) - cx,
        math.ceil(top + box_h) - cy,
        math.ceil(left + box_w) - cx,
    ]

# The EXPLORE title: a 768 x 128 box at (128, 96) on a 1024 x 1024 canvas
print(to_moss_bbox(128, 96, 768, 128, 1024, 1024))  # [-416, -384, -288, 384]

The same in JavaScript:

function toMossBbox(left, top, boxW, boxH, canvasW, canvasH) {
  const cx = canvasW / 2;
  const cy = canvasH / 2;
  return [
    Math.floor(top) - cy,
    Math.floor(left) - cx,
    Math.ceil(top + boxH) - cy,
    Math.ceil(left + boxW) - cx,
  ];
}

MOSS-Image canvas sizes are multiples of 16, so half the width and height are always whole numbers.

OpenMOSS's prompt enhancer skill works the same way: you draft boxes as [x_min, y_min, x_max, y_max] from the top-left, with the canvas width and height, and its compile_prompt.py script writes the compact abs_centralized / yxyx JSON. It rejects boxes that fall outside the canvas instead of silently clipping them.

A landscape exampleCopy Anchor Link

Here is a layout we wrote for a 1344×768 banner, the 16:9 size our generator uses. The x axis runs from −672 to +672 and the y axis from −384 to +384:

{
  "summary": {
    "meta": ["poster"],
    "canvas": "single",
    "caption": "A wide tech conference banner with a clean blue and violet gradient background and thin abstract circuit lines."
  },
  "items": [
    {
      "label": "text",
      "caption": "Large bold white title, centered in the upper half.",
      "text": "AI 开发者大会 2026",
      "bbox": [-224, -480, -64, 480]
    },
    {
      "label": "text",
      "caption": "Smaller light-gray English subtitle below the title.",
      "text": "AI Developer Summit",
      "bbox": [-32, -320, 48, 320]
    },
    {
      "label": "text",
      "caption": "A thin row of small white text along the bottom edge.",
      "text": "10月28日 · 深圳 · Oct 28 · Shenzhen",
      "bbox": [240, -400, 304, 400]
    }
  ],
  "bbox_coord_space": "abs_centralized",
  "bbox_format": "yxyx"
}

In top-left pixels, the title box spans x 192 to 1152 and y 160 to 320, the subtitle sits just below it, and the footer row runs along y 624 to 688. Move the boxes around to taste.

Using a layoutCopy Anchor Link

• Python: serialize the layout with json.dumps(layout, ensure_ascii=False) and pass the string as the prompt, with the same width and height the coordinates were written for. ensure_ascii=False keeps Chinese text readable instead of escaping it.
• Gradio (the official demo app): paste the JSON into the Prompt field and set the matching width and height.
• ComfyUI: the layout-guided templates build the layout for you. You draw boxes in Create Bounding Boxes, caption each one, and the MOSS-Image Layout Prompt node turns them into the prompt. See our MOSS-Image ComfyUI workflow guide.

import json

prompt = json.dumps(layout, ensure_ascii=False)
image = pipe(
    prompt,
    width=1024,
    height=1024,
    num_inference_steps=50,
    guidance_scale=3.0,
    uncond_skip_layers=[22],
).images[0]

pipe here is the Diffusers pipeline from the model card; our Base vs SFT guide shows how to load it.

On mossimage.studioCopy Anchor Link

Our MOSS Image AI generator works in text mode for now; a layout editor is coming. Text prompts already go through prompt expansion, which plans a structured layout from your description before generating and keeps the text you asked for. Describing positions clearly in words gets you a long way. Here is the EXPLORE poster as a text prompt:

Tips for good layoutsCopy Anchor Link

These follow the guidance in OpenMOSS's prompt enhancer skill:

• Box coherent units. One box for a title, one for a product, one for a paragraph. Split only when parts need to be placed independently.
• A box marks a position, not a frame. It does not draw a border, panel or sticker. If you want one, describe it in a caption.
• Overlap is fine. Natural occlusion, such as a title over a photo, is allowed.
• Exact words go in text, appearance goes in caption. Keep the visible string verbatim in text, including punctuation and line breaks, and describe its font, color and size in the caption.
• Global style goes in summary.caption. Palette, lighting and medium belong to the whole image.
• Keep captions and boxes consistent. A caption that says "at the top" should have a box at the top.
• Keep instructions out of captions. Captions describe what is visible. Notes about the JSON or the conversion belong somewhere else.

Common mistakesCopy Anchor Link

• Writing xyxy boxes. MOSS-Image expects [y_min, x_min, y_max, x_max].
• Forgetting to subtract the center. Top-left pixel coordinates put every box in the wrong place.
• Changing the canvas size. A layout written for 1024×1024 will not line up at 1344×768.
• Using normalized coordinates. Coordinates on a 0 to 1 or 0 to 1000 scale are not the format MOSS-Image layouts use.
• Boxes outside the canvas. Every coordinate must stay within half the width and half the height of the canvas.
